-Supply Voltage: DC 5V, 12V, 24V or AC 100V, 230V; other DC voltages available.
-Stroke: 0mm – 30mm.
-Action: Linear Pull and/or Push ( Thrust ) versions available.
-Coil Termination: Terminal tags option or Flying Wire leads option.
-UL recognized materials.
-Zinc plated Frame.
-Nickel plated Plunger.
･custom plunger and mounting available ;
･returned spring available ;
･connectors can be added to flying wire leads.
･rectifier can be added to coil for AC voltage.
Coils are wound and wrapped with UL Recognized
Materials. The Materials are compliant with RoHS &
Protect Safety, Health and Environment of our
employees in our operations.
Quality Control of Incoming Parts.
Quality Monitor and Control during Manufacturing Process.
Quality Assurance to Final Product before Shipping.
